JR Mica Products Co., Ltd is a high-tech company specializing in producing fire resistant mica tape and mica roll for fire resistant cable.

With advanced production and testing equipment ,JR Mica has capacity to produce 1000tons fire resistantmica tapes per year.

With senior engineers having more than 15 year experience in mica product industrial field ,JR Mica is producing high quality mica products strictly according to ISO9001:2008 quality management system.

Type of mica tape

Phlogopite mica tape

1)JR-P-GS:Single-side glass fiber reinforced phlogopite mica tape

2)JR-P-GD:Double-side glass fiber reinforced phlogopite mica tape

3)JR-P-FS:Single -side PE film reinforced phlogopite mica tape

4)JR-P-GFD:Double -side glass &PE film reinforced phlogopite mica tape

Muscovite mica tape

1)JR-M-GS:Single-side glass fiber reinforced Muscovite mica tape

Synthetic mica tape

1)JR-S-GS:Single-side glass fiber reinforced synthetic mica tape

2)JR-S-GD:Double-side glass fiber reinforced synthetic mica tape

3)JR-S-FS:Single -side PE film reinforced synthetic mica tape

4)JR-S-GFD:Double -side glass &PE film reinforced synthetic mica tape

Specifications

Width of mica tape:4.5mm-1000mm

Thickness of mica tape:0.08mm-0.18mm

Length of mica tape:300m-2000m

Inner diameter:52mm,76mm,100mm

Maximum length of re-winding spool can reached 50000M

Shelf -life:12 months at  good storekeeping conditions of dry,clean at roomtemperature.

High temperature resistance

JR-P phlogopite mica tape can ensure cable to pass fire testing at 750-950°C for 3 hours according to international standards of BS6387 and IEC60331 ,JR-S synthetic mica tape is suitable for fire resistant cable to fire at950-1050°C and JR-M calcinated muscovite mica tape is designed for cable to fire at1050°C.

mica tape for cable  advantage

High performance of fire resistant and environmentally friendly.

Good flexibility property and high tensile strength.

Maximum length of re-winding spool is 50000M.
