| 产品认证 | ce |
|---|---|
| 尺寸 | 16 mm x 39.5 mm x 12 mm |
| 重量 | 30 g |
| 防护等级 | IP 67 |
| 电源电压 | DC10...30（V） |
| 检测方式 | 漫反射式 |
| 结构类型 | 放大器内藏型 |
| 类型 | 光电式接近开关 |
| 使用环境温度 | -40 ... +60（℃） |
| 输出方式 | NPN |
| 用途 | 工业自动化仪器 |
| 品牌 | SICK/施克 |
| 型号 | WLG4-3N1382 |
| 加工定制 | 否 |
| 质量认证 | ce |
W4-3玻璃纤维反射式光电开关WLG4-3N1382
| Features | |||
| Sensor/detection principle: | Photoelectric retro-reflective sensor | ||
| Dimensions (W x H x D): | 16 mm x 39.5 mm x 12 mm | ||
| Housing design (light emission): | Rectangular | ||
| Sensing range max.: | 0.01 m ... 1.6 m 1) | ||
| Sensing range: | 0.02 m ... 0.9 m 2) | ||
| Type of light: | Visible red light | ||
| Light source: | PinPoint LED 3) | ||
| Wave length: | 650 nm | ||
| Special features: | Without polarisation filter | ||
| Adjustment: | Single teach-in button | ||
| Light spot size (distance): | ? 75 mm (1.5 m) | ||
| Continuous threshold adaption: | |||
| 1) 2) PL80A 3) Average service life of 100,000 h at TA = +25 °C |
| Mechanics/electronics | |||
| Supply voltage: | 10 V DC ... 30 V DC 1) | ||
| Ripple: | < 5 Vpp 2) 3) | ||
| Power consumption: | ≤ 20 mA 4) | ||
| Output type: | NPN | ||
| Switching mode: | Light switching | ||
| Output current Imax.: | ≤ 100 mA | ||
| Response time: | < 0.5 ms 5) | ||
| Switching frequency: | 1,000 Hz 6) | ||
| Angle of reception: | Ca. 30 ° | ||
| Attenuation along light beam: | > 8 % | ||
| Connection type: | Cable, 3-wire, 2 m 7) | ||
| Cable material: | PVC | ||
| Conductor cross-section: | 0.14 mm? | ||
| Cable diameter: | ? 3.4 mm | ||
| Circuit protection: | A, C, D 8) 9) 10) | ||
| Protection class: | III | ||
| Weight: | 30 g | ||
| Polarisation filter: | - | ||
| Optics material: | PMMA | ||
| Enclosure rating: | IP 67 IP 66 | ||
| Special feature: | Detecting transparent objects | ||
| Ambient operating temperature: | -40 °C ... +60 °C | ||
| Ambient storage temperature: | -40 °C ... +75 °C | ||
| Housing material: | ABS, Plastic | ||
